Fan YWF.A6T-800S-7DIIIA00 without mounting plate

Airflow direction:
Suction
Diameter:
800 mm
Voltage:
400 V
Frequency:
50 Hz
Air flow:
25000 m3/h
Speed:
900 min-1
Input power:
1850 W
Current:
3,7 A
Sound pressure level:
80 dB(A)
Internal thermal protection :
150±5 ºC
Protection class:
54 IP
Compliance with directive ERP 2015:
Yes
General efficiency:
35,3 ηstatA%
Efficiency ratio:
40,3
Net weight:
35,6 kg
Gross weight:
39,5 kg
Dimensions of package:
88 x 88 x 31 cm

Product description YWF.A6T-800S-7DIIIA00
