Fan YWF.A6T-800S-7DIIIA00
without mounting plate
- Airflow direction:
- Suction
- Diameter:
- 800 mm
- Voltage:
- 400 V
- Frequency:
- 50 Hz
- Air flow:
- 25000 m3/h
- Speed:
- 900 min-1
- Input power:
- 1850 W
- Current:
- 3,7 A
- Sound pressure level:
- 80 dB(A)
- Internal thermal protection :
- 150±5 ºC
- Protection class:
- 54 IP
- Compliance with directive ERP:
- 2015
- General efficiency:
- 35,3 ηstatA%
- Efficiency ratio:
- 40,3
- Net weight:
- 35,6 kg
- Gross weight:
- 39,5 kg
- Dimensions of package:
- 88 x 88 x 31 cm
Product description YWF.A6T-800S-7DIIIA00
